Đầu ghi hình 16 Camera IP Planet NVR-1610

NVR đầu ghi hình IP

  • MS : NVR-1610
  • Bảo hành : 12 tháng
  • Kho hàng : Còn hàng
  • Hãng sản xuất : Planet
  • Xuất xứ : Taiwan
  • Seri sản phẩm :

Số lượng mua
Thông số kỹ thuật
Tổng quan
Video
Download
Phụ kiện

Model

NVR - 1610

Video

Compression

MJPEG / MPEG-4 / H.264

Resolution

5 MP / HD / Mega-Pixel / FD1 / CIF / QCIF

Max. Frame Rate

480 fps (1280 x 1024, H.264)

Display Mode

Live View / Playback / Full Screen

PTZ Support

Virtual PTZ Panel / Auto Pan / Preset Point / Preset Sequence / Digital PTZ

Sequence Mode

Sequence All
Manually selected cameras in 1/4 split view with configurable timer

Snapshot

3 continuous snapshots in JPEG format

E-Map

Motion Detected Event Display on E-Map
Google Map

Recording Mode

Manual, Schedule, Event, Continuous

Hardware

Video Input

16 Channels IP Cameras

Ethernet

1 x RJ-45, 10/100/1000Base-T

USB Interface

1 x USB 2.0 for backup device and firmware upgrade

Storage Device

2 x 3.5" SATA II Hard Disk Connectors

Button

Power, Reset, Buzzer

LED Display

1 x Power
1 x Status
1 x LAN
2 x HDD
1 x Alarm
16 x IP Camera

Network and Configuration

Network File Protocol

Microsoft Networks (CIFS/SMB), Internet (HTTP), FTP

Network Service

TCP/IP, DHCP, DNS, HTTP, FTP, NTP, SMTP, UPnP

Management

Web-Based Administration
Network Time Protocol
Multiple Users Account
E-mail Notification
System Log
Firmware Upgrade

User Interface

Web Browser
CMS Utility

Environment

Power

100~240V AC, 1.4A / Max. 50/60Hz

Consumption

90W

Operating Temperature

0~45 Degree C

Storage Temperature

-40~70 Degree C

Humidity

0~90% (non-condition)

Weight

2.89 kg

Dimension (W x D x H)

170 x 215 x 125 mm
