Model |
NVR2048-36B |
System
|
Client-server architecture, Chassis: 1U 19" Rack |
Server Processor
|
IntelR Dual Core @2.5GHz |
System Memory
|
4GB, DDR2 |
I/O Interface |
RJ-45: 2xGigabit Ethernet SAS Expansion port |
Electrical |
Input voltage :115 V AC @ 6 A/240 V AC @ 3 A Frequency: 47 to 63 Hz Power: Single 250 watt |
Power Consumption |
Rated output power: 300 W |
Weight |
Gross weight: 17.3 kg (38 lb.) |
Dimensions |
50.4(W)x 43.7(D)x 4.3(H) cm (19.85 " x 17.2 " x 1.7 ") |
Environment |
- Temperature: Non-operating: -40° C to 70° C (-40° F to 158° F) - Humidity: |
Certificates |
FCC Class A, CE, CB, UL60959/ IEC 60950, CCC |
Model |
RAID Subsystem |
Host Connectivity |
1 or 2 SAS 4x wide ports per controller |
Drive Connectivity
|
SAS/SATA-II disk, 12 or 16 drives per system, hot |
Form Factor
|
2~3U, 19 inch rackmount |
RAID Functionality |
RAID 0, 1 (0+1), 3, 5, 6, 10, 30, 50, 60, hot-spare, |
Power |
12Bay: 350W; 16 Bay: 460W |
Cooling |
High or low rotation speed controlled by firmware |
Environment |
Operating temperature:: 5° C to 40° C (35° C if battery is applied) Non-operating: -40° C to 60° C Humidity: 5 % to 95 % non-condensing |
Dimensions |
12 Bay: chassis without handles: 446(W) x 88(H) x 490(D) mm; chassis with handles: 482 (W) x 88(H) x 505(D) mm |
Weight |
12 Bay: gross weight: 25kg; 16 Bay: 30.5kg |
Certification |
CE, FCC Class B, BSMI, UL, GOST-R |
Model |
VMS Specifications |
Live View
|
Real-time network camera discovery Versatile views of various screen divisions HTML and image overlays Multiple views supported View patrolling for single or multiple views Real time vidoe/event alarm display Instant playback Video clip bookmarking |
eMAP
|
Drag-n-drop camera manipulation Directional camera display Hierarchical map structure Real time event alert Instant live video of camera Multiple maps supported |
PTZ
|
Pan, tilt, zoom operations (dependent of camera) Built-in, floating PTZ control panel Preset position (dependent of camera) Scheduled or continous camera patrolling Event-driven camera patrolling On Screen PTZ control |
Multiple Displays |
Up to 8 monitors Supports live view, playback, eMap functions Direct display to secondary monitor(s) |
Investigation |
Search by date, time, camera Search by pre-defined recent time Search by VI event combinations Search over multiple days Search over multiple cameras Video clip bookmarking and commenting Search via built-in VI analyzer Customizable bookmark Intuitive, video thumbnail search results Cue-in, cue-out and repeat Quick playback by video thumbnail 1/8, 1/4, 1/2, 1x, 2x, 4x, 8x play, pause, stop AVI-formated video clip export |
Instant Playback |
Supported in video alarm, event alarm, view functions Pre-defined playback durations Video clip bookmarking |
Video Intelligence |
General motion detection Missing object detection Foreign object detection Intrusion detection Forbidden area detection Tampering detection Virtual fence Object counting |
Remote Management |
Full functional operation & management via standalone VMS Client |
Remote Client |
Web Client iPhone Client |
3rd Party IPCAM |
ACTi, Arecont Vision, Asoni, AVTECH, AXIS, Bosch, Dahua, HIKVISION, IQinVision, Lilin, MOBOTIX, Panasonic,SAMSUNG, SONY, VIVOTEK |
General & Misc |
Video codec: H.264, MPEG4, MJPEG Image enhancement Video privacy mask Digital zoom in, zoom out Log viewer Windows lockup Client auto login Digital I/O management Automatic storage recycling Client-server architecture Guaranteed performance of long period recording Customizable appearance of Surveon logo Configurable video retention period Digital watermark proofing Language supported: English, French, German, Portuguese, Spanish, Simple Chinese, Traditional Chinese, Italian, Japanese, Russian, Slovak, Czech, Dutch and Polish Support DDNS Function Support CH Products USB joystick Support etherent I/O device* Support NTP Server synchronized* |
