Model |
CAM4360 |
||
Image Sensor |
1/3" 2 megapixel progressive scan CMOS |
||
Lens |
3 - 10 mm motor lens, F1.3 |
||
SNR |
48dB |
||
WDR |
N/A |
||
Day/Night ICR |
Yes |
||
IR LED |
Yes (20M) |
||
Min. Illumination |
0.01 Lux @ F1.2 (B/W) 0.1 Lux @ F1.2 (Color) |
||
Iris Control |
DC drive |
||
Shutter Time |
1/7.5 ~ 1/100,000 s |
||
Viewing Angle |
Diagonal: 129°~34° |
||
Camera Angle |
Pan 0° ~340° |
||
Pan/Tilt/Zoom |
N/A |
||
Video Compression |
H.264/MPEG-4/MJPEG |
||
Resolution |
Up to 1920 x 1080 |
||
Frame Rate |
30 fps at 1080P (1920 x 1080) |
||
Video Stream |
Dual stream at H.264, MPEG-4, and MJPEG simultaneously |
||
Bit Rate |
64K ~ 6Mbps, VBR, CBR, controller frame rate and quality |
||
Video Control |
AGC (Auto Gain Control), AWB (Auto White Balance), AES (Auto Electronic Shutter), BLC (Back Light Compensation), image adjustment |
||
Intelligent Video |
Motion detection |
||
Video Jack |
N/A |
||
Built-in MIC |
N/A |
||
Audio Compression |
32KHz, ADPCM |
||
Audio Input |
3.5mm phone jack |
||
Audio Output |
3.5mm phone jack |
||
Alarm In |
2, terminal block |
||
Alarm Out |
1, terminal block |
||
Video Buffer |
5 second pre-alarm, 30 second post-alarm |
||
Event Action |
Send snapshot or video clip by FTP or email, record to NAS, record to local storage, trigger DO |
||
Supported Protocols |
IPv4, ARP, TCP, UDP, ICMP, DHCP, NTP, DDNS, SMTP, FTP, HTTP, CIFS, PPPoE, UPnP, RTP, RTSP, RTCP, 3GPP, ONVIF |
||
Ethernet |
10/100 Base-T / RJ45 |
||
Local Storage |
microSD/SDHC x 1 (Class 4/Class 6 only) |
||
RS-485 |
1 (2 pin on terminal block) (optional) |
||
USB |
N/A |
||
SDK |
Surveon SDK 2.0 |
||
OS |
Microsoft Windows XP/Vista/7 |
||
Browser |
Microsoft IE 6.0 or above |
||
Software |
Surveon VMS 2.4.1 |
||
emperature |
Operation: -25°C~ 50°C (-13°F~122°F) |
||
Humidity |
5 to 90% |
||
Power |
12VDC 1.5A;PoE (IEEE 802.3af) with Class 3 |
||
Power Consumption |
Max. 7.5W (w/o Heater ) |
||
Dimension (WxHxD) |
ø144mm x 116mm(H) |
||
Weight |
Net: 1,260g (2.78lb.) |
||
Certification |
|
